23 Mil. Film
Window Security Film
Shooter Attack Certified 23Mil. Film
Armoured One’s 23 Mil. Shooter Attack Film was invented to retrofit into existing windows to slow down or stop an active shooter, allowing law enforcement enough time to respond. Our film is applied to the innermost surface of your existing glass and anchored to your existing framing, making our films the fastest option to secure your building. We recommend this for exterior locations, such as windows at vestibules, doors, classroom exterior windows, office windows, large gathering room windows, and entry ways. Our film is much thicker and utilizes proprietary adhesive technology to achieve the strength that other films cannot.
- Designed to retrofit existing windows to slow down or prevent an active shooter from entering your building.
- Our film is the fastest way to secure your building since it can be seamlessly installed to any existing window.
- Our film has undergone rigorous testing and meets the highest standards, including the ASTM F-3561 certification and the FILTI Shooter Attack Certification.
- Recommend for exterior windows in areas such as vestibules, doors, classroom exterior windows, office windows, large gathering rooms, and entryways.
- 15-Year Limited Warranty Included
- Shooter Attack Certified, Forced Entry Protection, Bomb-Blast Resistant.
- Thickness: 5/16″
- Fire Rating: 20 Minute (Without Hose Stream)
- Glass Weight: 5 lbs. sq/ft
- Construction: Proprietary
- Maximum Size: 72″ X 96″
- Warranty: 15 Year Limited
Armoured One’s 23 Mil. Shooter Attack Film is the strongest security film available on the market, possessing some of the most difficult certifications to achieve.
ASTM F3561 – Standard Test Method for Forced-Entry-Resistance of Fenestration Systems After Simulated Active Shooter Attack.
FTD-SA-C1 – Class 1 Shooter Attack Test where the film is shot 10 times by an assault rifle shooting .223 rounds and then hit with a 100 lb. ram where the glass is struck minimally two (2) times at 50-foot pounds of force by the ram. If the ram penetrates the glass before the completion of the two hits, it is considered a failure. This test is completed by FILTI.
- ASTM F3561-22 (Active Shooter Certified)
- FTD-SA-C1 (Active Shooter Certified)
- ANSI Z97.1
- ASTM E84
- ANSI Z97.1
- 16 CFR 1201
- All Fire Certifications and Requirements
Installation is quick and minimally disruptive, making it an efficient option for securing buildings like schools without interfering with daily operations. The film is installed to the inner surface of existing glass and anchored to the existing framing, requiring no construction, window removal, or significant disruption. This makes our film the fastest and most affordable way to secure your building.
Standard: ASTM F3561 – Standard Test Method for Forced-Entry-Resistance of Fenestration Systems After Simulated Active Shooter Attack
Scope: Requirements and testing procedures to test forced-entry resistant building components to simulate an active shooter event in – commercial, residential, schools, government, and other institutional buildings
Test Procedure: The test consists of weakening of the fenestration system using ballistic projectiles (5.56 NATO, M193, 55 grain FMJ) which is followed by mechanically driven impacts using a forced entry impactor capable of delivering horizontal impacts of 400 ft-lbf to simulate the active shooter event.
End Result: The product achieves a Level of 1 – 8 for forced entry resistance.
Information From: Intertek.com.
CAUTION: Be wary of any security film that claims to be bullet proof or bullet resistant. There is no film in existence that will make existing glass bullet resistant (or bullet proof). If a company claims this, they are lying to you.
Armoured One Has The Strongest Film Available
*Our Film Is ASTM F3561 Tested & Certified. The Highest Standard Test Simulating An Active Shooter Attack.
At Armoured One LLC, we have rigorously tested and proven the superior strength of our 23 Mil. Security Film against our largest competitors. Many competitors market their products as security glass or film, but in reality, they offer only weather resistance. As shown in our video, these films are barely stronger than untreated 1/4 inch glass and can be easily punctured after being shot once with a 9mm round from a handgun. In stark contrast, our 23 Mil. Security Film withstands ten shots from an assault rifle shooting .223 rounds, followed by nine hits with a metal bat. Even after such extensive damage, the hole in our film remains significantly smaller than that of the competitors. Our film actively fights back, blowing back glass and debris at the attacker, obstructing their visibility and deterring further attacks. Choosing Armoured One means unmatched strength and security. Trust Armoured One for real protection, not just weather resistance.
Our Film Is The Fastest Option To Secure Your School
Our film was created to be your fastest option to get your school secure by modifying existing windows. It does not require any construction, window removal, blocking off areas of the school, or anything that can disrupt day to day operations. Our certified team of installers go into the school and apply the film to the inside of the existing glass, making this the easiest, fastest, and most affordable option to secure your buildings.
For eight tense minutes, our 23 Mil. Film stood between the attacker and the innocent students and staff he was planning on harming, providing police enough time to arrive and apprehend him.
SHOOTER ATTACK CERTIFIED 23 MIL. FILM
| Break Strength | 640 lbs/inch | Highest Rated Break Strength In The Industry |
| Elongation Strength | 230% | Highest Rated Elongation Strength In The Industry |
| Tensile Strength at Break | 35,000 | Highest Rated Tensile Strength In The Industry |
| Peel Strength | 10-11 lbs/inch | Highest Rated Peel Strength In The Industry |
| Forced Entry Test | UL972 | Anti-Burglary Test Method |
| Safety Standard For Architectural Glazing Material | ANSI Z97.1 | 16CFR CPSC1201 | Mandatory Building Code |
| Shooter Attack Test Method | FTD-SA-C1 (Third Party Tested) | Standard Test Method For Simulating An Active Shooter Attack |
Standard Test Method For Simulating An Active Shooter Attack
OPTICAL AND SOLAR PRODUCT SPECIFICATION
Table Key:
* Optical And Solar Performance Simulated Using LBNL Software’s (Optics And WINDOW 5.2) According NFRC Methodology
| No. | Parameter | Test Method | Measurement Tool | Spec | Unit | Comments |
|---|---|---|---|---|---|---|
| 1 | Haze | ASTM D 1003 | Haze Gard Plus | <4 | % | Film Only |
| 2 | Color B | ASTM D 2244 | MiniScan XE Plus | 4.2 | N/A | CIE-LAB D65/10 Film Only |
| 3 | Visible Light Transmitted | (*) Table Key | CARY 500 Scan Spectrophotometer | 87 | % | Performance Data On 1/8” Clear Glass |
| 4 | Visible Light Reflected (Int) | (*) Table Key | CARY 500 Scan Spectrophotometer | 12 | % | Performance Data On 1/8” Clear Glass |
| 5 | Visible Light Reflected (Ext) | (*) Table Key | CARY 500 Scan Spectrophotometer | 12 | % | Performance Data On 1/8” Clear Glass |
| 6 | UV Block | (*) Table Key | CARY 500 Scan Spectrophotometer | >99 | % | Performance Data On 1/8” Clear Glass |
| 7 | Total Solar Energy Reflected | (*) Table Key | CARY 500 Scan Spectrophotometer | 11 | % | Performance Data On 1/8” Clear Glass |
| 8 | Total Solar Energy Transmitted | (*) Table Key | CARY 500 Scan Spectrophotometer | 77 | % | Performance Data On 1/8” Clear Glass |
| 9 | Total Solar Energy Absorbed | (*) Table Key | CARY 500 Scan Spectrophotometer | 12 | % | Performance Data On 1/8” Clear Glass |
| 10 | Shading Coefficient | (*) Table Key | CARY 500 Scan Spectrophotometer | 0.93 | N/A | Performance Data On 1/8” Clear Glass |
| 11 | Total Solar Energy Rejected | (*) Table Key | CARY 500 Scan Spectrophotometer | 19 | % | Performance Data On 1/8” Clear Glass |
| 12 | Solar Heat Gain Coefficient | (*) Table Key | CARY 500 Scan Spectrophotometer | 0.81 | N/A | Performance Data On 1/8” Clear Glass |
| 13 | U-Value Winter | (*) Table Key | CARY 500 Scan Spectrophotometer | 1.03 | N/A | Performance Data On 1/8” Clear Glass |
| 14 | K-Value Winter | (*) Table Key | CARY 500 Scan Spectrophotometer | 5.85 | N/A | Performance Data On 1/8” Clear Glass |
| 15 | Glare Reduction | (*) Table Key | CARY 500 Scan Spectrophotometer | 3 | % | Performance Data On 1/8” Clear Glass |
